Crozet, Albemarle County · June 2025
Albemarle Vineyard: Coordinated Multi-Building Drainage Project
The problem
Working vineyard between Crozet and Free Union with four buildings draining onto interconnected lawn space. Original gutter and drainage planning had been done piecemeal as buildings were added over a decade. Main residence, tasting room (converted from a 1960s barn), production building, and small office cottage. Result was a wet-zone problem in the lawn near the tasting room patio that turned to mud during events. Vineyard owner wanted the issue resolved before the busy fall tasting season.
What we did
Designed and installed a coordinated drainage plan rather than re-quoting individual gutter systems. Replaced gutters on three of the four buildings with appropriately-sized 6-inch commercial-profile aluminum (the production building required true commercial scale; the cottage and tasting room used residential-spec). All ten downspouts connected to a buried 6-inch SCH 40 PVC trunk line running 80 feet downhill to a daylight discharge into a new gravel-lined dry creek bed. The dry creek doubled as a landscape feature visible from the tasting patio.
How it turned out
First fall tasting season after install ran without any patio mud or lawn flooding even after multiple heavy rain events. Vineyard owner reports they no longer think about drainage during event planning. The dry creek bed has become an unintentional landscape feature that guests photograph. We retain the property on annual cleaning and inspection.
Why coordinated drainage matters
Most of our work is single-building residential. Once or twice a year we get a project that’s bigger and more interesting. A multi-building property where the gutter conversation has to expand into a real drainage plan.
This vineyard between Crozet and Free Union had been dealing with a frustrating problem for years. Four buildings on the working acres of the property. Main residence, tasting room (a converted 1960s pole barn), small production building, and an office cottage. Were each draining onto the same lawn space at the back of the property. Each building’s gutters had been replaced or installed by different contractors over a decade, with no coordinated drainage plan. The downstream effect was a persistent wet zone exactly where the tasting room patio met the lawn, which turned to mud whenever the property held an outdoor event during a wet stretch.
The vineyard owner described the symptom: “Every fall, we’re putting down hay or wood chips before events because that one corner is mud. We’ve spent more time and money managing the mud than I want to admit.”
What we found at walk-through
We walked the property with the owner and the vineyard’s facilities lead on a Tuesday morning. Findings:
- Main residence: 5-inch K-style aluminum, recently replaced (3 years prior), in good shape. No work needed on the gutter itself; downspouts discharged to splash blocks pointed in three different directions, two of which ended in the problem zone.
- Tasting room: 5-inch K-style aluminum, 8 years old, undersized for the converted barn’s roof catchment area. Multiple corners where water sheeted over the front during heavy rain. Three downspouts, all discharging within 6 feet of the patio.
- Production building: 5-inch K-style on what was effectively a commercial-scale roof. Dramatically undersized. Two downspouts that should have been four, draining at a rate that overwhelmed the discharge points during any meaningful rain.
- Office cottage: Acceptable existing gutters; one downspout discharging into the wet zone.
The pattern was clear: every building was sending water into the same lawn area, with no coordinated discharge plan. Even with all the gutters working perfectly, the cumulative volume was still creating the mud problem.
The plan
We proposed a coordinated drainage project rather than four separate gutter quotes. Approach:
- Replace the production building’s gutters with 6-inch commercial-profile aluminum on heavier-spec hangers. Add two more downspouts (going from two to four).
- Replace the tasting room’s gutters with 6-inch K-style residential-profile aluminum. Reposition downspouts to feed into the trunk line (rather than discharge near the patio).
- Modify the main residence and office cottage by tying their existing downspouts into the new buried trunk line at convenient points. No new gutter work; just discharge redirection.
- Install a 6-inch SCH 40 PVC trunk line running 80 feet from the building cluster to a designed daylight discharge at the back of the property.
- Build the discharge as a dry creek bed. Gravel-lined, planted with appropriate water-tolerant landscaping, visible from the patio as a designed landscape feature rather than a utility outlet.
Total bid presented as a single project price with itemized line items so the owner could see what was structural gutter work versus what was drainage versus what was landscape integration.
The install
Eight days on site spread across three weeks (around scheduled vineyard events).
Days 1-3: Trunk line trenching and installation. We coordinated with the vineyard to avoid disrupting a planned wedding. The trunk line was buried at 30 inches below grade, well below frost line, with cleanouts at three junction points.
Days 4-5: Production building gutter replacement. The commercial-scale work; significant material weight. Used a small lift to manage the higher hanger placement.
Days 6-7: Tasting room and cottage downspout work. Connecting existing residential gutters into the new trunk line at planned tie-in points.
Day 8: Dry creek discharge bed construction. Gravel base, native plantings, and visual integration with the patio sightlines.
Photo documentation
Extensive. This was one of those projects where the documentation became almost as important as the install. (Pending customer permission to publish; placeholder gallery here until then.)
What we’d do again
The biggest decision on this project was scoping it as a single coordinated drainage plan rather than four gutter quotes. That decision came from the owner’s framing. “I don’t want another contractor quoting me a gutter when the problem is the water”. And it was the right framing. Treating each building’s gutters as an isolated quote would have produced a more expensive project that didn’t actually solve the mud issue.
The dry creek discharge feature was an experiment that worked. We’d done buried daylight discharges plenty of times, but rarely with explicit landscape integration. The vineyard owner’s design eye made the discharge into a feature rather than a utility detail. We’ve since done two similar installs on other estate properties with the same approach.
